LVM System Administration

How to Use LVM for Home Directories in Multiuser Environment

LVM or Logical Volume Manager is a powerful tool in Linux for managing storage. With LVM, you can create logical disk volumes to organize your data. The LVM volumes are easy to resize, so it’s a great alternative to Linux quota. In this article, I will show you how to use LVM for home directories in a multiuser environment. So, let’s get started.

Requirements:

You need at least a spare partition or a hard drive on your computer to configure LVM based home directories.

I recommend you use a dedicated hard drive in a production environment. If you’re learning, then using a partition is just fine.

Installing LVM:

On Ubuntu, you can install LVM from the official package repository of Ubuntu.

First, update the APT package repository cache with the following command:

$ sudo apt update

Now, install LVM with the following command:

$ sudo apt install lvm2

Now, press y and then press <Enter>.

LVM should be installed.

If you’re using CentOS 7 or RHEL 7, you can install LVM with the following command:

$ sudo yum install lvm

Initial Setup of LVM:

Now, you have to tell LVM which partition or hard drive you want to manage with LVM. In order to do that, you need to know the device name of the partition or hard drive you want to use.

You can find the device name of the partition or hard drive with the following command:

$ lsblk | egrep "disk|part"

All the partitions and hard drives installed on your computer should be listed. Here, I am going to use the dedicated hard drive sdb to configure LVM. But you can also use a partition such as sda2, sda3, sdb2 or whatever you have.

Now, create a LVM physical volume of your hard drive with the following command:

$ sudo pvcreate /dev/sdb

NOTE: Replace sdb with the device name of your hard drive or partition.

Now, create a LVM volume group (let’s call it home) of your hard drive with the following command:

$ sudo vgcreate home /dev/sdb

Creating LVM Logical Volumes for Users:

Now, you have to create the required logical volumes for each of your login users and use it as the home directory.

Let’s say, we have 3 users, lily, linda and bob. User lily and linda wants 512 MB of disk space and bob wants 2 GB of disk space.

To create a 512 MB logical volume for lily, run the following command:

$ sudo lvcreate -L 512M -n lily home
Or
$ sudo lvcreate --size 512M --name lily home

The same way, create a 512 MB logical volume for linda with the following command:

$ sudo lvcreate -L 512M -n linda home

Now, create a 2 GB logical volume for bob with the following command:

$ sudo lvcreate -L 2G -n bob home

Now, you have to format the logical volumes that you just created. I will use EXT4 filesystem.

To format the logical volume of lily /dev/home/lily, run the following command:

$ sudo mkfs.ext4 -L lily /dev/home/lily

To format the logical volume of linda /dev/home/linda, run the following command:

$ sudo mkfs.ext4 -L linda /dev/home/linda

To format the logical volume of bob /dev/home/bob, run the following command:

$ sudo mkfs.ext4 -L bob /dev/home/bob

Creating Users:

Now, let’s create the users lily, linda and bob. I will use the useradd command to create the users because the useradd command does not create a home directory by default.

To create the user lily, run the following command:

$ sudo useradd lily

Now, set a password for the user lily with the following command:

$ sudo passwd lily

Now, type in the password you want to set for the user lily. The password should be set.

The same way, create the user linda with the following command:

$ sudo useradd linda



Also, set a password for the user linda with the following command:

$ sudo passwd linda

Again, create the user bob with the following command:

$ sudo useradd bob

Now, set a password for the user bob with the following command:

$ sudo passwd bob

Mounting LVM Logical Volumes as Home Directories:

Now, you have to create the mount points for the LVM logical volumes that you’ve just created. As they are going to be the home directories of lily, linda and bob, the mount points should be /home/lily, /home/linda, and /home/bob respectively.

To create the mount point for the user lily, run the following command:

$ sudo mkdir /home/lily

To create the mount point for the user linda, run the following command:

$ sudo mkdir /home/linda

To create the mount point for the user bob, run the following command:

$ sudo mkdir /home/bob

Now, open the /etc/fstab file with the following command:

$ sudo nano /etc/fstab

Now, type in the following lines at the end of the file. Once you’re done, save the file with <Ctrl> + x followed by y and then press <Enter>.

Now, to mount the LVM logical volumes to the user home directories, run the following command:

$ sudo mount -a

Now, to confirm that the LVM logical volumes are mounted correctly, run the following command:

$ df -h | grep /home

As you can see, the LVM logical volumes are mounted correctly for each user.

Now, you have to fix the permissions for each mounted LVM logical volumes. Otherwise, the users won’t be able to create or delete any files. Also, you should copy all the files from the /etc/skel directory to each home directory.

To copy the files from the /etc/skel directory to the home directories, run the following commands:

$ sudo cp -RT /etc/skel /home/lily
$ sudo cp -RT /etc/skel /home/linda
$ sudo cp -RT /etc/skel /home/bob

Now, fix the permissions of lily’s home directory with the following command:

$ sudo chown -Rf lily:lily /home/lily

To fix the permissions of linda’s home directory, run the following command:

$ sudo chown -Rf linda:linda /home/linda

To fix the permissions of bob’s home directory, run the following command:

$ sudo chown -Rf bob:bob/home/bob

As you can see, the correct permissions are assigned to each home directory.

You can also login as any of the users and it should work.

So, that’s how you use LVM for user home directories in multi user environment in Linux. Thanks for reading this article.
