How to customize the tmux configuration?

Tmux is an open-source terminal multiplexer application for efficiently managing multiple terminal windows. People who have previously used the Terminator application are primarily familiar with the notion of tab management in Linux Terminal. With Tmux, we can split the terminal into a number of panes. We can adjust these panes by moving around, resizing, and switching between them. This helps in curbing the pain of managing multiple windows and tabs of the Gnome terminal.

In general, when you close an SSH connection, the corresponding remote terminal sessions are also closed. Here comes the Tmux for help as it preserves those sessions when the SSH connection is terminated.

After installing Tmux, you will not find any icon associated with it. It will not appear as a separate application; instead, we will have to invoke it from the Gnome Terminal itself. We will later see how to do this.

Note: In this ‘HowTo’ we have used the ‘Ctrl+b’ as the prefix; if you configured some other prefix, then replace the command with yours’ prefix.

What will we cover?

This guide will learn about “How to customize tmux configuration?”. We will use Ubuntu 20.04 as the base system for this guide.

Prerequisites

1. Tmux should be installed on your system.

2. Internet connectivity and user account with ‘sudo’ privileges.

Using tmux.conf for Customization of Tmux

To customize the tmux configuration, we need to tweak its default configuration file: tmux.conf. This file is invoked by Tmux at startup. Tmux first looks for the system configuration file inside the directory ‘/etc/tmux.conf’, if it is absent, it then searches inside the home directory of the user. The file contains a list of Tmux commands which are executed sequentially. These commands are executed at the very first start of the tmux server.

Note: Before going to customize the tmux.conf, beware that you do not spoil up the configuration by mixing multiple shortcuts. In order to avoid such ambiguity, you should view all the occupied shortcuts of Tmux by entering the below command inside a Tmux session:

1. Changing the default ‘Ctrl+b’ or ‘C-b’ prefix to ‘Alt+b’ or ‘M-b.’

The prefix key (‘Ctrl+b’) along with a command key controls various operations of Tmux. It is the default combination which most users will tend to change for handiness. But changing this key requires some wit so that we may not mess up with other shortcuts of the default terminal we are working on.

Let us change this prefix to ‘Alt+b.’ Open the tmux.conf file. If it is in your home directory, use the command:

Put the below lines in this file and save it.

If you are inside a Tmux session, exit the current session and start over a new Tmux session. You can also reload the tmux config file to make the changes work.

2. Setting both the ‘Ctrl+b’ and ‘C-b’ as prefixes.

We can also set two prefixes; for example, the below tmux commands will set both the ‘Alt+b’ and ‘Ctrl+b’ as prefixes. Open the tmux.conf file and enter:

Now reload the ‘tmux.conf’ file.

3. Using the Mouse mode.

We can use the ‘tmux.conf’ file to set the scrolling behavior of the mouse. Open the file and put the following line:

Now reload tmux.conf using the command:

Once the above tasks are done, we can use the touchpad or PC mouse to scroll our Tmux terminal.

4. Adding shortcut for tmux config reload

Many times we customize tmux frequently to suit our needs; as a result, we need to reload the config file very often. The command to reload tmux.conf when it is running is:

Let us create a handy shortcut for this. Open the tmux.conf file and put the following line in it:

Next time you need to reload the config file, you only have to enter the prefix followed by ‘r.’

5. Simplifying the Split commands

The Tmux default shortcut for splitting the terminal is very awkward. Let’s change it into something more convenient. E.g., we will be mapping the horizontal split to ‘-’ from ‘ “ ‘ and the vertical split from ‘%’ to ‘|.’

Open the tmux.conf file and add the below lines:

6. Managing copy-paste operation between System clipboard and Tmux clipboard

It is straightforward to copy the contents from the System clipboard and paste it to a Tmux session using the regular key combination ‘Ctrl+Shift+v.’ However, the reverse procedure is not that straightforward. We can simplify this by installing a utility called ‘xclip’ and customizing the ‘tmux.conf’ file. Follow the steps given below:

Step 1. First, install ‘xclip’ on Ubuntu 20.04 using the command:

We have already installed it:

Step 2. We will now customize tmux.conf by adding the below line:

The first line makes the ‘prefix’ followed by ‘Ctrl+c’ to capture the current Tmux buffer and feeds this output to ‘xclip.’ Now, we can paste the copied text from the Tmux clipboard using the system clipboard:

The second line configures the ‘prefix’ followed by ‘Ctrl+v’ to paste text from the system clipboard to a Tmux session, but as stated earlier, it is straightforward to copy and paste from the system clipboard to Tmux session (Using Ctrl+Shift+v). So you may not need the second line. If this does not work, then you must add the second line.

Tips: We can also define a keybinding that will not need a prefix. E.g., to reload the configuration file using ‘Ctrl+r’ only, use the bind command as shown here:

But this will disable this particular key combination in other applications running in a Tmux session, so use it carefully.

Conclusion

In this guide, we have learned many ways of customizing Tmux configuration using tmux.conf. There are still many ways to change the look and feel of a Tmux environment. A more detailed explanation of various Tmux operations can be found on the Tmux Man pages or on the Github page of Tmux.
