How to Create and Mount Btrfs Subvolumes

A Btrfs subvolume works just like a directory, but it has its own file tree. So, you can mount Btrfs subvolumes separately as they have their own file tree. You also need to create subvolumes to take snapshots of your important data.

This article will show you how to create and delete Btrfs subvolumes, mount Btrfs subvolumes, and automatically mount Btrfs subvolumes using the /etc/fstab file. So, let’s get started.

Prerequisites

To try out the examples of this article,

  • You must have the Btrfs filesystem installed on your computer.
  • You need to have a hard disk or SSD with at least 1 free partition (of any size).

I have a 20 GB hard disk sdb on my Ubuntu machine. I have created 2 partitions sdb1 and sdb2 on this hard disk. I will use the partition sdb1 in this article.

$ sudo lsblk -e7

Your hard disk or SSD may have a different name than mine, so will the partitions. So, make sure to replace them with yours from now on.

If you need any assistance on installing the Btrfs filesystem on Ubuntu, check my article Install and Use Btrfs on Ubuntu 20.04 LTS.

If you need any assistance on installing the Btrfs filesystem on Fedora, check my article Install and Use Btrfs on Fedora 33.

Creating a Btrfs Filesystem

To experiment with Btrfs subvolumes, you need to create a Btrfs filesystem.

To create a Btrfs filesystem with the label data on the sdb1 partition, run the following command:

$ sudo mkfs.btrfs -L data /dev/sdb1

A Btrfs filesystem should be created.

Create a directory /data with the following command:

$ sudo mkdir -v /data

To mount the Btrfs filesystem created on the sdb1 partition in the /data directory, run the following command:

$ sudo mount /dev/sdb1 /data

The Btrfs filesystem should be mounted as you can see in the screenshot below.

$ df -h /data

Creating Btrfs Subvolumes

A Btrfs subvolume is just like a directory in your Btrfs filesystem. So, you need to specify a directory path to create a Btrfs subvolume in that directory path. The path must point to a Btrfs filesystem where you want to create the subvolume.

For example, to create a Btrfs subvolume in the path /data/photos (the Btrfs filesystem is mounted in the /data directory), run the following command:

$ sudo btrfs subvolume create /data/photos

A Btrfs subvolume /data/photos should be created.

Let’s create some more Btrfs subvolumes.

Create a Btrfs subvolume /data/videos with the following command:

$ sudo btrfs subvolume create /data/videos

Create a Btrfs subvolume /data/documents with the following command:

$ sudo btrfs subvolume create /data/documents

Create a Btrfs subvolume /data/projects with the following command:

$ sudo btrfs subvolume create /data/projects

As you can see, a new directory is automatically created for each of the subvolumes.

You can list all the subvolumes of your Btrfs filesystem (mounted on the /data directory) as follows:

$ sudo btrfs subvolume list /data

As you can see, all the subvolumes we have created are listed.

You can find a lot of information about a Btrfs subvolume (let’s say /data/projects) like the subvolume name, the subvolume UUID, the subvolume ID etc. as follows:

$ sudo btrfs subvolume show /data/projects

Let’s create some dummy files in each of the Btrfs subvolumes. Once we mount the Btrfs subvolumes separately, the files in each of the subvolumes should be there.

To create some dummy files in the /data/projects subvolume, run the following command:

$ sudo touch /data/projects/file{1..3}

To create some dummy files in the /data/photos subvolume, run the following command:

$ sudo touch /data/photos/file{4..6}

To create some dummy files in the /data/videos subvolume, run the following command:

$ sudo touch /data/videos/file{7..8}

To create some dummy files in the /data/documents subvolume, run the following command:

$ sudo touch /data/documents/file{9..10}

Right now, this is how the Btrfs filesystem mounted on the /data directory looks like.

$ tree /data

Mounting Btrfs Subvolumes

To mount a Btrfs subvolume, you need to know either its name or its ID.

You can find the name or the ID of all the Btrfs subvolumes created on the Btrfs filesystem mounted on the /data directory as follows:

$ sudo btrfs subvolume list /data

Let’s mount the projects Btrfs subvolume. The projects Btrfs subvolume has the ID 261.

I will mount the Btrfs subvolume projects in the /tmp/projects directory to show you how to mount a Btrfs subvolume.

Create a directory /tmp/projects as follows:

$ sudo mkdir -v /tmp/projects

You can mount the projects Btrfs subvolume (which is available in the Btrfs filesystem created on the sdb1 partition) using its name projects in the /tmp/projects directory as follows:

$ sudo mount /dev/sdb1 -o subvol=projects /tmp/projects

The projects subvolume should be mounted on the /tmp/projects directory as you can see in the screenshot below.

$ sudo btrfs subvolume show /tmp/projects

You can also see that the Btrfs filesystem (the projects subvolume) is mounted on the /tmp/projects directory.

$ df -h -t btrfs

All the files you have created in the projects subvolume are also available in the /tmp/projects directory as you can see in the screenshot below.

$ tree /tmp/projects

Now, let’s see how to mount a Btrfs subvolume using its ID.

Before that, umount the projects subvolume from the /tmp/projects directory as follows:

$ sudo umount /tmp/projects

You can mount the projects Btrfs subvolume (which is available in the Btrfs filesystem created on the sdb1 partition) using its ID 261 in the /tmp/projects directory as follows:

$ sudo mount /dev/sdb1 -o subvolid=261 /tmp/projects

The projects subvolume should be mounted on the /tmp/projects directory as you can see in the screenshot below.

$ sudo btrfs subvolume show /tmp/projects

You can also see that the Btrfs filesystem (the projects subvolume) is mounted on the /tmp/projects directory.

$ df -h -t btrfs

All the files you have created in the projects subvolume are also available in the /tmp/projects directory as you can see in the screenshot below.

$ tree /tmp/projects

Removing Btrfs Subvolumes

In this section, I am going to show you how to remove a Btrfs subvolume.

Let’s create a Btrfs subvolume test on the Btrfs filesystem mounted on the /data directory as follows:

$ sudo btrfs subvolume create /data/test

As you can see, the test subvolume is created on the Btrfs filesystem mounted on the /data directory.

$ sudo btrfs subvolume list /data

To remove the test Btrfs subvolume, run the following command:

$ sudo btrfs subvolume delete /data/test

NOTE: If you delete a Btrfs subvolume, all the files/directories in that subvolume will also be removed.

As you can see, the Btrfs subvolume test is removed.

$ sudo btrfs subvolume list /data

Automatically Mount Brtfs Subvolumes at Boot Time

In this section, I will show you how to mount the Btrfs subvolumes of the Btrfs filesystem created on the sdb1 partition (mounted on /data directory now).

First, unmount the Btrfs filesystem, which is mounted on the /data directory as follows:

$ sudo umount /data

I want to mount the Btrfs subvolumes in their respective directories. Let’s create some directories where we can mount the Btrfs subvolumes.

To create the directories documents, projects, photos, and videos, run the following command:

$ sudo mkdir -pv /data/{documents,projects,photos,videos}

Find the UUID of the Btrfs filesystem on the sdb1 partition as follows:

$ sudo blkid  /dev/sdb1

As you can see, the UUID of the Btrfs filesystem is 0b56138b-6124-4ec4-a7a3-7c503516a65c.

Now, edit the /etc/fstab file with the nano text editor as follows:

$ sudo nano /etc/fstab

Type in the following lines in the /etc/fstab file:

# Mount the Btrfs subvolumes to their respective directories
UUID=0b56138b-6124-4ec4-a7a3-7c503516a65c   /data/projects
btrfs   subvol=projects    0   0
UUID=0b56138b-6124-4ec4-a7a3-7c503516a65c   /data/documents
btrfs   subvol=documents   0   0
UUID=0b56138b-6124-4ec4-a7a3-7c503516a65c   /data/photos
btrfs   subvol=photos      0   0
UUID=0b56138b-6124-4ec4-a7a3-7c503516a65c   /data/videos
btrfs   subvol=videos      0   0

NOTE: Make changes as required.

Once you’re done, press <Ctrl> + X followed by Y and <Enter> to save the /etc/fstab file.

For the changes to take effect, reboot your computer with the following command:

$ sudo reboot

Once your computer boots, the Btrfs subvolumes should be mounted on their respective directories as you can see in the screenshot below.

$ df -h -t btrfs

Conclusion

In this article, I have shown you how to create and delete Btrfs subvolumes, mount Btrfs subvolumes, and automatically mount Btrfs subvolumes using the /etc/fstab file. This article should help you get started with the subvolume feature of the Btrfs filesystem.
