How to Check if a Filesystem is Mounted in Linux

The OS(operating system) employs the file system which is known as the file system in a computer language that is commonly abbreviated to “fs”. The “fs” is a technique that regulates how well the piece of information is protected and accessed. Without a file system, the content of the file in a memory device would not distinguish between one type of information. The information can be easily extracted and recognized by making the groups and assigning each group a name. Each group of information is referred to as a “file,” which is a terminology derived from a paper-based data management system. A “file system” is the term referring to both the organizational framework and logical principles that are used to handle the names and groupings of information.

Different Techniques of Checking the Filesystem Mounted Type in Linux

There are many different file system varieties in Linux that will provide several terminal commands and techniques to check the filesystem mounted type in Linux. Let us just start delving and fully understanding how well the filesystem functions in terms of understanding the various filesystem varieties in Linux and how we are going to execute each method one at a time.

Prerequisite: Installing util-linux

To use the root privileges of accessing the different types of file systems in Linux, we will first write the “sudo” keyword in the Linux terminal. Then, we will write the “apt” which will upgrade the deb packages. To access the mounted files system in the Linux, we use different steps to install the “util-linux” as seen below:

linux@linux-VirtualBox:~ sudo apt install util-linux

After writing the “sudo” command, we first have to enter the password of the Linux then it will show further details.

[sudo] password for linux:

Reading package lists... Done

Building dependency tree

Reading state information... Done

util-linux is already the newest version (2.34-0.1ubuntu9.3).

0 upgraded, 0 newly installed, 0 to remove and 31 not upgraded.

After installing the “util-linux”, now we can easily apply the different techniques to check the filesystem mounted type.

Technique 01: The “fsck” Command

The Linux command fsck stands for File System Consistency Check which analyzes filesystems for faults or unresolved problems.

Step: 01

The instruction employed to produce statistics and correct potential problems is written below:

linux@linux-VirtualBox:~$ sudo fsck -N

fsck from util-linux 2.34

[/usr/sbin/fsck.ext4 (1) -- /] fsck.ext4 /dev/sda5

[/usr/sbin/fsck.vfat (1) -- /boot/efi] fsck.vfat /dev/sda1

To get the certain filesystem, we will write the path of the filesystem which we want to get:

linux@linux-VirtualBox:~$ sudo fsck –N /dev/sda5

fsck from util-linux 2.34

[/usr/sbin/fsck.ext4 (1) -- /] fsck.ext4 /dev/sda5

Step: 02

To get additional information on the “fsck” statement, use the “man fsck” statement. Following is the full command:

linux@linux-VirtualBox:~$ man fsck

Technique 02: The “mount” Command

The “mount” statement will provide all the mounted devices along with the filesystem format and mounted location in Linux.

Step 01:

To get the mounted filesystem’s type, we will write first the “mount” keyword along with “grep” so that we can only get those mounted files that we want to display. This is why we have provided the “^/dev” path.

linux@linux-VirtualBox:~$ mount | grep “^/dev”

/dev/sda5 on / type ext4 (rw,relatime,errors remount-ro)

/dev/sda1 on /boot/efi type vfat (rw, relatime, fmask=0077, dmask=0077,codepage=43

7,iocharset=iso8859-1, shortname-mixed, errors=remount-ro)

Step: 02

To understand more clearly about the “mount” command, write the below INSTRUCTION:

linux@linux-VirtualBox:~$ man mount

Technique 03: The “findmnt” Command

Now, we are going to implement another technique to check the filesystem type which is “findmnt” statements in Linux. In the findmnt statement, it will show all the mounted filesystems in the device.

Step: 01

The “findmnt” statement returns the target, source, and fstype which means file system type and the options which contain whether the file is read/write or read-only. At the top of the tree of the filesystem, it will be the root directory and here it is “ext4”.

linux@linux-VirtualBox:~$ findmnt

TARGET                                SOURCE      FSTYPE OPTIONS

/                                     /dev/sda5   ext4   rw,relatime,errors=rem

├─/sys                                sysfs       sysfs  rw,nosuid,nodev,noexec

│ ├─/sys/kernel/security              securityfs  securi rw,nosuid,nodev,noexec

│ ├─/sys/fs/cgroup                    tmpfs       tmpfs  ro,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/unified          cgroup2     cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/systemd          cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/rdma             cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/cpu,cpuacct      cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/cpuset           cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/net_cls,net_prio cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/blkio            cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/misc             cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/perf_event       cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/devices          cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/pids             cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/memory           cgroup      cgroup rw,nosuid,nodev,noexec

│ │ ├─/sys/fs/cgroup/hugetlb          cgroup      cgroup rw,nosuid,nodev,noexec

│ │ └─/sys/fs/cgroup/freezer          cgroup      cgroup rw,nosuid,nodev,noexec

│ ├─/sys/fs/pstore                    pstore      pstore rw,nosuid,nodev,noexec

│ ├─/sys/fs/bpf                       bpf         bpf    rw,nosuid,nodev,noexec

│ ├─/sys/kernel/debug                 debugfs     debugf rw,nosuid,nodev,noexec

│ ├─/sys/kernel/tracing               tracefs     tracef rw,nosuid,nodev,noexec

│ ├─/sys/fs/fuse/connections          fusectl     fusect rw,nosuid,nodev,noexec

│ └─/sys/kernel/config                configfs    config rw,nosuid,nodev,noexec

├─/proc                               proc        proc   rw,nosuid,nodev,noexec

│ └─/proc/sys/fs/binfmt_misc          systemd-1   autofs rw,relatime,fd=28,pgrp

│   └─/proc/sys/fs/binfmt_misc        binfmt_misc binfmt rw,nosuid,nodev,noexec

├─/dev                                udev        devtmp rw,nosuid,noexec,relat

│ ├─/dev/pts                          devpts      devpts rw,nosuid,noexec,relat

│ ├─/dev/shm                          tmpfs       tmpfs  rw,nosuid,nodev,inode6

│ ├─/dev/mqueue                       mqueue      mqueue rw,nosuid,nodev,noexec

│ └─/dev/hugepages                    hugetlbfs   hugetl rw,relatime,pagesize=2

├─/run                                tmpfs       tmpfs  rw,nosuid,nodev,noexec

│ ├─/run/lock                         tmpfs       tmpfs  rw,nosuid,nodev,noexec

│ └─/run/user/1000                    tmpfs       tmpfs  rw,nosuid,nodev,relati

│   └─/run/user/1000/gvfs             gvfsd-fuse  fuse.g rw,nosuid,nodev,relati

├─/snap/bare/5                        /dev/loop0  squash ro,nodev,relatime,erro

├─/snap/glances/1243                  /dev/loop1  squash ro,nodev,relatime,erro

├─/snap/core20/1778                   /dev/loop2  squash ro,nodev,relatime,erro

├─/snap/core20/1738                   /dev/loop3  squash ro,nodev,relatime,erro

├─/snap/glances/1168                  /dev/loop4  squash ro,nodev,relatime,erro

├─/snap/gnome-3-38-2004/115           /dev/loop5  squash ro,nodev,relatime,erro

├─/snap/gnome-3-38-2004/119           /dev/loop6  squash ro,nodev,relatime,erro

├─/snap/gtk-common-themes/1535        /dev/loop7  squash ro,nodev,relatime,erro

├─/snap/snap-store/558                /dev/loop8  squash ro,nodev,relatime,erro

├─/snap/snap-store/638                /dev/loop9  squash ro,nodev,relatime,erro

├─/snap/snapd/17883                   /dev/loop10 squash ro,nodev,relatime,erro

└─/boot/efi                           /dev/sda1   vfat   rw,relatime,fmask=0077

Step: 02

If you want to dig deeper into the understanding of the “findmnt” command:

linux@linux-VirtualBox:~$ man findmnt

Here is the detailed information about the “findmnt” command which was open on another Linux man terminal page. If you want to go back to the man terminal page, you have to press “q” to exit the “man findmnt” terminal.

Technique 04: The “file” Command

The “file” statement, which is employed to verify the kind of a certain file, is a further technique we will employ in the filesystems in Linux.

Step: 01

Below is a different example where we are checking the different filesystems while giving the different filesystems paths.

linux@linux-VirtualBox:~$ sudo file –sL /dev/sda1

/dev/sda1: DOS/MBR boot sector, code offset 0x58+2, OEM-ID "mkfs.fat", sectors/ cluster 8, Media descriptor 0xf8, sectors/track 63, heads 255, hidden sectors 2048, sectors 1048576 (volumes > 32 MB), FAT (32 bit), sectors/FAT 1024, reserve d 0x1, serial number 0x58c97606, unlabeled

linux@linux-VirtualBox:~$ sudo file –sL /dev/sda5

/dev/sda5: Linux rev 1.0 ext4 filesysten data, UUID=6e3d13f8-16f7-4e12-bff8-8ca 1bbb6d0bd (needs journal recovery) (extents) (64bit) (large files) (huge files)

Step: 02

Write the following command on the terminal and hit enter if you want further information:

linux@linux-VirtualBox:~$ man file

Technique 05: The “blkid” Command

The “blkid” statement is another technique of the filesystem in Linux which is used to find and print the block device’s information.

Step: 01

To access the information of blocked devices, we will simply write the blkid command in the terminal.

linux@linux-VirtualBox:~$ sudo blkid

As shown in the terminal, we have gotten the information along with the type of the filesystem.

/dev/sda5: UUID="6e3d13f8-16f7-4e12-bff8-8ca1bbb6d0bd" TYPE="ext4" PARTUUID="e8ce01c9-05"

/dev/loop0: TYPE="squashfs"

/dev/loop1: TYPE="squashfs"

/dev/loop2: TYPE="squashfs"

/dev/loop3: TYPE="squashfs"

/dev/loop4: TYPE="squashfs"

/dev/loop5: TYPE="squashfs"

/dev/loop6: TYPE="squashfs"

/dev/loop7: TYPE="squashfs"

/dev/sda1: UUID="58C9-7606" TYPE="vfat" PARTUUID="e8ce01c9-01"

/dev/loop8: TYPE="squashfs"

/dev/loop9: TYPE="squashfs"

/dev/loop10: TYPE="squashfs"

In the “blkid” command, if we want to display the information of the specific device, then we will write the path of the device which we want to get after writing the “sudo blkid” in the terminal.

linux@linux-VirtualBox:~$ sudo blkid /dev/sda1

/dev/sda1: UUID="58C9-7606" TYPE="vfat" PARTUUID="e8ce01c9-01"

Step: 02

We can access the “man” page of the “blkid” phrase in Linux and view additional details about it by typing the command below.

linux@linux-VirtualBox:~$ man blkid

Technique 06: The “df” Command

Here is another technique to figure out the overall disc space and free space on a Linux filesystem, by utilizing the “df” command in the terminal.

Step: 01

Let us just learn how to examine the quantity of free space still available in the Linux filesystem using the “df” statement. As you see below, we have got the filesystem which is the name of the mounted filesystem and it will also display the type.  The “1k-blocks” is the size that is represented in one-kilo blocks and the free and used storage of the mounted filesystem.

linux@linux-VirtualBox:~$ sudo df -T

Filesystem     Type     1K-blocks    Used Available Use% Mounted on

udev           devtmpfs   1970752       0   1970752   0% /dev

tmpfs          tmpfs       401852    1360    400492   1% /run

/dev/sda5      ext4      25107716 9980164  13826816  42% /

tmpfs          tmpfs      2009244       0   2009244   0% /dev/shm

tmpfs          tmpfs         5120       4      5116   1% /run/lock

tmpfs          tmpfs      2009244       0   2009244   0% /sys/fs/cgroup

/dev/loop0     squashfs       128     128         0 100% /snap/bare/5

/dev/loop1     squashfs     10112   10112         0 100% /snap/glances/1243

/dev/loop2     squashfs     64896   64896         0 100% /snap/core20/1778

/dev/loop3     squashfs     64768   64768         0 100% /snap/core20/1738

/dev/loop4     squashfs     10240   10240         0 100% /snap/glances/1168

/dev/loop5     squashfs    354688  354688         0 100% /snap/gnome-3-38-2004/115

/dev/loop6     squashfs    354688  354688         0 100% /snap/gnome-3-38-2004/119

/dev/loop7     squashfs     93952   93952         0 100% /snap/gtk-common-themes/1535

/dev/loop8     squashfs     55552   55552         0 100% /snap/snap-store/558

/dev/loop9     squashfs     47104   47104         0 100% /snap/snap-store/638

/dev/loop10    squashfs     50816   50816         0 100% /snap/snapd/17883

/dev/sda1      vfat        523248       4    523244   1% /boot/efi

tmpfs          tmpfs       401848      28    401820   1% /run/user/1000

Step: 02

We shall type the man df statement on the terminal to obtain extra knowledge about the “df” statement:

linux@linux-VirtualBox:~$ man df

Technique 07: The “fstab” Command

This technique will hold the static information of the filesystem in Linux.

Step: 01

We first write the “cat” command so that we can access the filesystem information and then we write the path /etc/fstab.

linux@linux-VirtualBox:~$ cat /etc/fstab

# /etc/fstab: static file system information.

#

# Use 'blkid' to print the universally unique identifier for a

# device; this may be used with UUID= as a more robust way to name devices

# that works even if disks are added and removed. See fstab(5).

#

# <file system> <mount point>   <type>  <options>       <dump>  <pass>

# / was on /dev/sda5 during installation

UUID=6e3d13f8-16f7-4e12-bff8-8ca1bbb6d0bd /               ext4    errors=remount-ro 0       1

# /boot/efi was on /dev/sda1 during installation

UUID=58C9-7606  /boot/efi       vfat    umask=0077      0       1

/swapfile                                 none            swap    sw              0       0

Step: 02

The following command can be used to dig deeply into the “fstab” statement:

linux@linux-VirtualBox:~$ man fstab

Technique 08: The “lsblk” Command

The “lsblk” technique is utilized to show data on block devices, which except for RAM discs, are essentially files that indicate linked devices.

Step: 01

We have used “-f” in the command so that we can represent the arguments of the files.

linux@linux-VirtualBox:~$ lsblk -f

NAME FSTYPE LABEL UUID                         FSAVAIL FSUSE% MOUNTPOINT

loop0
     squash                                                  0   100% /snap/bare
loop1
     squash                                                  0   100% /snap/glan
loop2
     squash                                                  0   100% /snap/core
loop3
     squash                                                  0   100% /snap/core
loop4
     squash                                                  0   100% /snap/glan
loop5
     squash                                                  0   100% /snap/gnom
loop6
     squash                                                  0   100% /snap/gnom
loop7
     squash                                                  0   100% /snap/gtk-
loop8
     squash                                                  0   100% /snap/snap
loop9
     squash                                                  0   100% /snap/snap
loop10
     squash                                                  0   100% /snap/snap
sda
├─sda1
│    vfat         58C9-7606                               511M     0% /boot/efi
├─sda2
│
└─sda5
     ext4         6e3d13f8-16f7-4e12-bff8-8ca1bbb6d0bd   13.2G    40% /


sr0

Step: 02

Use the command below to see the additional information on the “lsblk” statement:

linux@linux-VirtualBox:~$ man lsblk”

Technique 09: The “udevadm” Command

The udevadm command is one of the techniques which we are going to use to check the filesystem type. The udev library is queried for device information using the udevadm command. But it also contains information about the filesystem type in Linux.

Step 01:

To check the file system type, the very first command we are going to use is the “udevadm” command in the Linux terminal. Write the following command in the Linux terminal:

linux@linux-VirtualBox:~$ udevadm info –query=property /dev/sda1 | egrep “DEVNAME|ID_FS_TYPE”

We have used the above command to query the database for the desired file type of device data with the “—query” statement. If we simply write the “udevadm –query”, the terminal will show us a lengthy output. This is why we have to use the “grep” statement that will show the necessary information to determine the file system type by further writing the “/dev/sda1” path.

DEVNAME=/dev/sda1

ID_FS_TYPE=vfat

Step 02:

To get further details about the “udevadm” command in the Linux, we will use the “man” command in the Linux terminal:

linux@linux-VirtualBox:~$ man udevadm

The udevadm command will be opened into a new terminal of the Linux as shown below in the snapshot:

Conclusion

We have learned what is filesystem and how to check the type of mounted filesystem in Linux. We have discussed the different techniques of the mounted filesystem by writing every command of the filesystem type in the Linux terminal.



About the author

Omar Farooq

Hello Readers, I am Omar and I have been writing technical articles from last decade. You can check out my writing pieces.
